Industry Applications

Sigmetrix tolerance analysis and GD&T software solutions help engineers, designers and product managers from a variety of industries bring robustness and accuracy to their designs, significantly improving product quality while drastically reducing production costs. For industry-specific tolerance analysis and GD&T application examples and case studies, please select from the following:

Automotive
Med Dev & Pharma
Aerospace & Defense
Electric Power Distribution
Electronics & Communication
HVAC & Appliances
Pumps & Compressors

Powertrain
Chassis
Electrical

Medical Dev & Pharma

It’s all about controlling the design and Staying Out of the News! Medical device companies recognize the need for accurate, precise tolerance analysis and GD&T solutions. Utilizing Sigmetrix’ CETOL 6σ and GD&T Advisor products empower our customers to:

Comply with increased regulatory requirements
Products are predictable and inherently safe
Validate software tool internally
Allow for easy reporting
Balance quality and cost

Because of the unique regulatory requirements and significant liability issues inherent in many markets today, the more visibility a medical device engineer has into the actual performance of the design after manufacturing, the greater his ability is to control risk via the design and minimize liability exposure.

Medical device companies recognize the need for accurate, precise tolerance analysis solutions. Medical device industry customers consist of leaders in the following areas:

Blood monitoring and diabetes care
Imaging
Implantable devices

Aerospace & Defense

It can be really difficult to repair a satellite that’s already in orbit, a weapon that’s in use in the field, or the landing gear on a jet that took off hours ago. The aerospace and defense industry represents one of the biggest sectors that Sigmetrix’ serves. Our CETOL 6σ tolerance analysis and GD&T Advisor products enable some of the industry’s leading companies to expand their precision assembly engineering and design tolerance analysis all the way from early concept design through inspection, providing product development teams the ability to deliver higher-quality and more precisely engineered products.

Key projects:

Satellite systems
Landing gear
Missile systems

Electric Generation Distribution

Energy generation, distribution and maintenance are key when trying to supply power to cities, allowing vehicles to run on just electricity, supplying power to regular household electronics and more. When trying to adhere to strict regulatory standards for production, understanding how your products are manufactured and will fit together is critical to success.

Production flexibility and failure reduction are hard to achieve when manufacturing products with complex variation data. Sigmetrix visualizes and simplifies variation data to provide key analytics, helping to capture and share critical information that reduces waste while increasing product flexibility.

Circuit Breakers
Windmills/Wind Energy
Electric Motors

PCB
Batteries
Pins and Connectors

Electronics & Communication

Using Sigmetrix’ tolerance analysis and GD&T software solutions early in the consumer products design process and concept stages enables designers and engineers to recognize potential problems, find a better design, and produce more reliable, higher-quality products at a lower cost, with dramatically reduced recall and warranty issues.

In the consumer products industry, warranty issues and product recalls are always in the back of designers and manufacturers’ minds. Improving the design and manufacturing processes helps ease those worries. An effective tolerance analysis forecast & review helps ensure that the specifications mandated during the design phase will work down the line in manufacturing, and that the end result – the product, will not only satisfy the consumer’s needs but will do so for the required amount of time at an effective cost.

Key projects:

Printer cartridge
Cellular phone
Camera focus

HVAC & Appliances

Keeping your cool in the HVAC industry is no easy task. With warranty and quality issues always in the picture, industry leaders use CETOL 6σ software for assembly variation & GD&T analysis, to save hundreds of thousands of dollars every year by creating more robust, reliable designs. Engineers & parts manufactures depend on GD&T declarations to ensure parts assembly and warranties are viable for longer periods of time. By identifying the tolerances of various parts during inception and prototyping time to production and final product reduces costs and long term maintenance expenses.
